CHAPTER 2: OVERVIEW
FIGURE 2-14. STATUS—MATRIX VIEW (EXAMPLE #2)
The colors indicate the connection status.
TABLE 2-17. STATUS LEDS
COLOR IN FIGURES 2-13 AND 2-14 DESCRIPTION
Gray Port not connected
Yellow Video connection
Green KVM connection
Red Faulty port
Blue Port connected to another matrix via grid line
