CHAPTER 2: OVERVIEW
The symbol indicates the extender that is recognized and defined at a certain port.
TABLE 2-18. SYMBOLS
SYMBOL DESCRIPTION
—
—
Port connected to a CPU Unit
—
—
P
Port is connected to a CPU Unit that is switched to a CON Unit in Private Mode
Port connected to a CON Unit
Port connected to a CON Unit with Shared Access to a CPU
P
Port is connected to a CON Unit that is connected to a CPU Unit in Private Mode
CPU
Port connected to a USB 2.0 CPU Unit
CON
Port connected to a USB 2.0 CON Unit
CSC
CON
Port is configured as Cascade-CON port for cascading of matrices
CSC
CPU
Port is configured as Cascade-CPU port for cascading of matrices
UNI
Port is a UNI port of an I/O board that can be used for USB 3.0 or SDI switching
