SERVSWITCH™
12
Temperature
Tolerance— 32 to 131°F (0 to 55°C)
Humidity
Tolerance— 5 to 80% noncondensing
Maximum
Altitude— 10,000 ft. (3048 m)
Enclosure — Steel
Power — SW721A-R5:
From wallmount external power supply (type may vary,
refer to labeling on transformer):
Either:
Input: 90 to 260 VAC at 50 or 60 Hz, 65 to 130 mA;
Output: +8 VDC at 1.5 A, –8 VDC at 375 mA;
or:
Input: 90 to 264 VAC at 47 to 63 Hz, 78 to 156 mA;
Output: +12 VDC at 1 A, –12 VDC at 0.5 A;
Consumption: Up to 15 VA (15 watts);
All other models;
From AC outlet through included power cord and
IEC 320 male inlet to UL
®, CUL, and TÜV approved
internal transformer:
Input: 100 to 240 VAC at 50 or 60 Hz, 450 mA;
Output: +5 VDC at 1.5 A, +12 VDC at 1 A;
Consumption: Up to 19.5 VA (19.5 watts)
Size — SW721A-R5:
1.8" (1U) H x 8.8"W x 4.8"D (4.5 x 22.5 x 12.4 cm);
SW722A-R5, KV3108SA-R5:
1.8" (1U) H x 16.8"W x 4.8"D (4.5 x 42.5 x 12.4 cm);
SW723A-R5, SW724A-R5, SW725A-R5:
3.5" (2U) H x 16.8"W x 4.8"D (8.9 x 42.5 x 12.4 cm)
Weight — SW721A-R5: 2 lb. (0.9 kg);
SW722A-R5: 3 lb. (1.4 kg);
KV3108SA-R5: 4 lb. (1.8 kg);
SW723A-R5: 5 lb. (2.3 kg);
SW724A-R5, SW725A-R5: 6 lb. (2.7 kg)
