2.3 The Front Panel
The front panels of the ServSwitch feature two or three pushbutton switches and
several LED indicators. To familiarize yourself with these controls and indicators,
refer to Figures 2-1, 2-2, and 2-3 below and the descriptions that follow on the next
page.
Figure 2-1. The front panel of a 2 to 1 ServSwitch (SW721A-R5).
Figure 2-2. The front panel of a slimline 8 to 1 ServSwitch (KV3108SA-R5).
Figure
2-3. The front panel of a 16 to 1 ServSwitch (SW725A-R5).
