89
Exterior Equipment
10.5 Helm Seats & Cooler
Helm Seats
The helm seats are equipped with a ip up bolster
to provide more room between the seats and the
helm. The bolster converts the seat to a leaning
post style seat with a backrest, allowing the opera-
tor and passenger to sit or stand at the helm. To
convert each seat to a leaning post, lift the front
of the seat cushion to raise the bolster and push
it back above the seat cushion.
A molded in footrest on the rear of the console
makes the helm more comfortable when the bol-
sters are set to the seat position.
Leaning Post Cooler
The cooler is secured below the leaning post in
special chocks mounted to the cockpit with stretch
cords. To remove the cooler, disconnect the stretch
cords and lift it out of the chocks. Reverse the
process to install the cooler. Make sure the cooler
is secured with the stretch cords before operating
the boat.
Notice:
Access to the fuel tank sending unit is located
below a removable hatch that is accessible
when the cooler is removed.
Helm Seats In Leaning Post Position
Helm Seats In The Seat Position
Cooler Chocks & Stretch CordsSeat Base & Cooler Chocks
