Recording
12
Codec Resolution Maximum Frame Rate
Blackmagic URSA
Maximum Frame Rate
Blackmagic URSA Mini
ProRes 444 XQ 1920 x 1080
(full sensor area)
120 Available in a later
software update
ProRes 444 120 Available in a later
software update
ProRes HQ 120 60
ProRes 422 120 60
ProRes LT 120 60
ProRes Proxy 120 60
ProRes 444 XQ 1920 x 1080
(windowed sensor area)
150 Available in a later
software update
ProRes 444 150 Available in a later
software update
ProRes HQ 150 120
ProRes 422 150 120
ProRes LT 150 120
ProRes Proxy 150 120
To select your desired codec and resolution:
Step 1. Press the 'menu' button on the control panel.
Step 2. Navigate to the ‘recording’ menu and select your desired ‘codec’ by tapping the codec
selection arrows on the touchscreen.
Step 3. Tap the relevant selection arrows for your desired resolution.
Step 4. If you want to record in HD using a windowed sensor area, so you can take advantage of
the higher frame rates, tap on the selection arrows to select 'window'. If you want to record
using the full sensor area, select 'full'.
Step 5. Press the 'menu' button to exit.
Maximum Sensor Frame Rates Continued
