Creating a sizing preset in the Sizing palette of the Color page
Optional Audio andKeyKode Reader
The optional Audio and KeyKode Reader expands your Cintel scanner’s capabilities
bycapturing optical and magnetic soundtracks at any speed, from slow to faster than real time.
It can also scan KeyKode information about the frame’s position in the reel and film stock used.
The reader has the following components.
1. Optical audio tracking knob 2. Magnetic audio head 3. Optical audio scanner
4. Capstan roller cleaning knob 5. Capstan roller
6. KeyKode scanner 7. Headphone port 8. USB firmware port
Upper film track
Lower film track
1
4 5
3
2
7 8
6
44Optional Audio andKeyKode Reader
