Mini Converter Quad SDI to HDMI 4K
Your Mini Converter Quad SDI to HDMI 4K can connect single link, dual link and quad link SDI
Ultra HD to the latest Ultra HD projectors and televisions that support Ultra HD over a single
HDMI link. You can also convert any of the following inputs to HDMI:
SD SDI
HD-SDI
Singlelink 3G-SDI
Singlelink 6G-SDI
Duallink HD-SDI
Dual link 3G-SDI Ultra HD
Quad link HD-SDI Ultra HD
If the HDMI output detects an HD monitor or HDTV, the output signal is automatically
downconverted. Only use inputs 1 and 2 with a valid dual link signal.
POWER
+12V
SDI IN 4
SDI IN 3
SDI IN 2
SDI IN 1
Quad SDI
to HDMI 4K
HDMI OUT
1
3
2
4
7
6
5
Connectors
Supported formats are listed under each SDI input:
1 SDI IN 1
ͽ SD/HD-SDI
ͽ Single link 3G-SDI
ͽ Single link 6G-SDI
ͽ Dual link HD-SDI channel A
ͽ Dual link 3G-SDI Ultra HD channel A
ͽ Quad link HD-SDI Ultra HD channel A
2 SDI IN 2
ͽ Dual link HD-SDI channel B
ͽ Dual link 3G-SDI Ultra HD channel B
ͽ Quad link HD-SDI Ultra HD channel B
3 SDI IN 3
ͽ Quad link HD-SDI Ultra HD channel C
4 SDI IN 4
ͽ Quad link HD-SDI Ultra HD channel D
Blackmagic Mini Converters 79
