Use the ‘audio’ tab in Converters Setup to adjust audio levels.
Mini Converter HDMI to SDI 6G Block Diagram
Analog or AES/EBU
Audio Switch
Central
Processor and
Firmware
SDI Out
SDI Out
Video Processor
and Down
Converter
SDI Audio
Embedder
AES/EBU
Sample Rate
Converter
Audio Analog to
Digital with
Balanced Input
HDMI Video and
Audio Decoder
Automatic
SD/HD/Ultra HD
Cable Driver
USB
Mini Switches
HDMI In
Right Analog In
Left Analog In
or AES/EBU
Mini Converter SDI to Analog
Your Blackmagic Mini Converter SDI to Analog converts from SD/HD-SDI to analog component,
NTSC and PAL video out, plus balanced AES/EBU and analog audio out. Your converter easily
connects to analog video monitors and decks such as Betacam SP and VHS. A hardware down
converter lets you connect HD-SDI video to SD analog equipment. You can even output pairs
of analog audio from 16de-embedded SDI audio channels.
