Operating Manual BMP-320
Maintenace
7.6 Drum Replacement
Prior to any repair works on the machine and its drives,
secure the machine against unintentional switching-on. Put
the machine to its safety off position. Chapter 2.6
Disassembly:
1 Loosen the fastening screws on the side plate fitted to the housing
and remove them, pull off the side-plate.
Fig. 7.1
6
