BMP-320 Operating Manual
Spare parts / Assembly plans
10.2 Assembly plans
Only assemble tools and spacers so you while the tools could freely
move (Axial-clearance min 1-2mm).
Every shaft needs to have the same quantity of tools and spacers
being fitted in order to prevent unbalances.
The following assembly layouts show the minimum components.
Drums can be assembled with more tools, depending on the surface
that needs to be treated.
Please follow the above mentioned information.
