91
INTRODUCTION NAVIGATION RADIO CD / MP3 CD CHANGER SETUP APPENDIX
●
IGNITion - Positive ignition connection
Switch on the ignition. ON appears alongside IGNITion.
●
SPEED - Speedometer connection
Move the vehicle a short distance. If the system detects the presence of the
speedometer signal it starts counting the pulses.
4 Press the ESC button = to return to the installation menu.
You can start calibrating the device after the test. There are 2 options available
to you for this.
Automatic device calibration
The TravelPilot E1/E2 must be calibrated after it is installed.
Note: The navigation CD-ROM must already be inserted in the drive
before you can do this.
1 Mark and confirm the AUTOmatic CALIBration menu item.
✔ The system displays a message asking you to drive 3 to 10 miles (5 to 15 km)
with GPS reception. Wait approx. 15 seconds or press the OK button ;. An
indicator bar will appear together with a figure in percent informing you of the
progress of the calibration process.
2 Now start driving.
✔ The menu closes automatically when the calibration process has completed
(the indicator bar fills completely and the system displays 100%).
Note: You must drive along major national roads (A-roads) or main
secondary roads (country roads) during calibration. The length of
the route that is specified by the system is only an average value. It
can also be shorter or considerably longer if conditions are poor.
The final fine calibration is completed after approximately 31 miles
(50 km).
INST. TEST
AUTO CALIB
MAN. CALIB
ins=all
NAV
T
MC
au=o Calib
NAV
T
MC
O%
RESTART?
