BLEMO ER12 - Page 20

21
Power terminals
Arrangement of the power terminals
ER12
Applicable wire
size (1)
Recommended
wire size (2)
Tightening
torque (3)
mm
2
(AWG) mm
2
(AWG) N·m (lb.in)
ER12-0.18KU
ER12-0.37KU/BU
ER12-0.18K
to
ER12-0.75K/B
ER12-0.18/3K
to
ER12-0.75/3K/B
2 to 3.5
(14 to 12)
2
(14)
0.8 to 1
(7.1 to 8.9)
(1)The value in bold corresponds to the minimum wire gauge to permit secureness.
(2)75˚C (167 ˚F) copper cable (minimum wire size for rated use)
(3)Recommended to maximum value.
ER12
Applicable
wire size (1)
Recommended
wire size (2)
Tightening
torque (3)
mm
2
(AWG) mm
2
(AWG) N·m (lb.in)
ER12-0.75KU
ER12-1.5K
ER12-2.2K
3.5 to 5.5
(12 to 10)
5.5
(10)
1.2 to 1.4
(10.6 to 12.4)
ER12-1.5/3K/B
ER12-2.2/3K/B
2 to 5.5
(14 to 10)
2 (14)
3.5 (12)
ER12
Applicable
wire size (1)
Recommended
wire size (2)
Tightening
torque (3)
mm
2
(AWG) mm
2
(AWG) N·m (lb.in)
ER12-3.0/3K/B
ER12-4.0/3K/B
5.5 (10) 5.5 (10)
1.2 to 1.4
(10.6 to 12.4)
