39
Monitoring mode MOn
Code Name/Description
StAt
• Product status
This parameter shows the state of the drive and motor.
rdY
rUn
ACC
dEc
dCb
CLI
nSt
Obr
CtL
tUn
FSt
nLP
• Drive ready
• Drive running, the last six segments to the right of the code also indicate direction and speed.
• Acceleration, the last six segments to the right of the code also indicate direction and speed.
• Deceleration, the last six segments to the right of the code also indicate direction and speed.
• DC injection braking in progress
• Current limit, the four segments located on right down of display are blinking.
• Freewheel stop control
• Auto-adapted deceleration
• Controlled stop on mains phase loss
• Auto-tuning in progress
• Fast stop
• No line power. When the control part is energized via the RJ45 connector and there is no power on
the main input and no run order is present.
