Monitoring mode MOn
Code Name/Description Unit
MAI-
Maintenance menu
Parameters of MAI menu can’t be selected for monitoring
LIS1
• State of logic inputs LI1 to LI4
-
Can be used to visualize the state of the 4 logic inputs LI.
Example above: LI1 and LI3 are at 1; LI2 and LI4 are at 0.
LOS1
• State of the logic output LO1 and relay R1
-
Can be used to visualize the state of the LO.
HSU
• Display of high speed value
Hz
Display of high speed value. Range Low speed LSP page 44 to Maximum frequency tFr page 55. Visible
only if 2 HSP assignment SH2 or 4 HSP assignment SH4 page 76
is configured.
nCU
• Drive Power rating
-
Indicates the drive rating. This is part the of the drive reference, see page 10. Possible values:
= 0.18 kW (0.25 HP)
= 0.37 kW (0.50 HP)
= 0.55 kW (0.75 HP)
= 0.75 kW (1 HP)
= 1.5 kW (2 HP)
= 2.2 kW (3 HP)
= 3 kW (3 HP)
= 4 kW (5 HP)
UCAL
• Drive voltage rating
-
Drive rate supply voltage. This is part the of the drive reference, see page 10. Possible values:
= 100-120 V 1 phase in, 200-240 V 3 phase out
= 200-240 V 1 phase in, 200-240 V 3 phase out
= 200-240 V 3 phase in, 200-240 V 3 phase out
SPn
• Specific Product Number
-
This parameter is used in order to identify the possible specification of the product.
Visible only if SPn is different to zero.
C1SU
• Card 1 Software Version
-
Application software version.
Example: 1105 for 1.1 ie 05.
1 (version, major). 1 (version, minor). 05 (ie, evolution number)
C2SU
• Card 2 Software Version
-
Motor software version.
Example: 1105 for 1.1 ie 05.
1 (version, major). 1 (version, minor). 05 (ie, evolution number)
State 1
State 0
LI1 LI2 LI3 LI4
State 1
State 0
r1 LO1
