51
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
I_O-
Input Output menu (continued)
AI1-
AI1 configuration menu
AI1t
• AI1 type
5U
5U
10U
0A
This function makes interface from the analog input signal to a drive internal value.
• Voltage: 0-5 Vdc
• Voltage: 0-10 Vdc
• Current: x-y mA. Range determined by the AI1 current scaling parameter of 0% CrL1 and AI1 current
scaling parameter of 100% CrH1 settings below, see page 51
.
CrL1
• AI1 current scaling parameter of 0%
0 to 20 mA 4 mA
Visible only if AI1 type AI1t is set to 0A
CrH1
• AI1 current scaling parameter of 100%
0 to 20 mA 20 mA
Visible only if AI1 type AI1t is set to 0A
I_O-
Input Output menu (continued)
r1
• R1 assignment
FLt
nO
FLt
rUn
FtA
FLA
CtA
SrA
tSA
ULA
OLA
AP1
• Not assigned
• No error detected
• Drive run
• Frequency threshold reached
• HSP reached
• I threshold reached
• Frequency reference reached
• Motor thermal reached
• Underload alarm
• Overload alarm
• AI1 Al. 4-20 - Visible only if AI1t is set to 0A (see above)
I-O-
drC-
CtL-
FUN-
FLt-
COM-
