70
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PId-
PID menu
PIF
• PID feedback assignment
nO
nO
A11
• Not assigned
• Terminal. Choice not possible if Fr1 is set to AI1
rPG
• PID proportional gain
0.01 to 100 1
Visible only if PID feedback assignment PIF is not set to nO.
rIG
• PID integral gain
0.01 to 100 1
Visible only if PID feedback assignment PIF is not set to nO.
rdG
• PID derivative gain
0.00 to 100.00 0.00
Visible only if PID feedback assignment PIF is not set to nO.
FbS
• PID feedback scale factor
0.1 to 100.0 1.0
This parameter gives the relation between process range and feedback range.
Visible only if PID feedback assignment PIF is not set to nO.
PII
• Activation internal PID reference
nO
nO
YES
Visible only if PID feedback assignment PIF is not set to nO.
• No
• Yes
Pr2
• 2 preset PID assignment
nO
nO
L1H
L2H
L3H
L4H
Visible only if PID feedback assignment PIF is not set to nO.
• No
• L1h
• L2h
• L3h
• L4h
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
