Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PId-
PID menu (continued)
Pr4
• 4 preset PID assignment
nO
nO
L1H
L2H
L3H
L4H
Visible only if PID feedback assignment PIF page 70 is not set to nO.
• No
• L1h
• L2h
• L3h
• L4h
2 preset PID assignment Pr2 page 70
must be assigned before assigning 4 preset PID assignment Pr4.
rP2
• 2 preset PID reference
0 to 100% 25%
Visible only if PID feedback assignment PIF page 70 and 2 preset PID assignment Pr2 page 70 are not set
to nO.
rP3
• 3 preset PID reference
0 to 100% 50%
Visible only if PID feedback assignment PIF page 70 and 4 preset PID assignment Pr4 page 70 are not set
to nO.
rP4
• 4 preset PID reference
0 to 100% 75%
Visible only if PID feedback assignment PIF page 70 and 2 preset PID assignment Pr2 and 4 preset PID
assignment Pr4 page 70
are not set to nO.
rPI
• Internal PID reference
0 to 100% 0%
Visible only if PID feedback assignment PIF page 70 is not set to nO and if Activation internal PID reference
PII page 70
is set to YES or Reference channel 1 Fr1 page 44 is set to LCC.
PrP
• PID reference ramp
0 to 100% 0%
Visible only if PID feedback assignment PIF page 70 is not set to nO.
rPL
• PID min value reference
0 to 100% 0%
Visible only if PID feedback assignment PIF page 70 is not set to nO.
rPH
• PID max value reference
0 to 100% 100%
Visible only if PID feedback assignment PIF page 70 is not set to nO
SFS
• PID predictive speed
0.1 to 400 Hz nO
This parameter allows to go directly to a set speed reference.
Visible only if PID feedback assignment PIF page 70
is not set to nO.
Parameter that can be modified during operation or when stopped.
