72
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PId-
PID menu (continued)
AC2
• Acceleration 2
0.0 to 999.9 s 5.0 s
This parameter is active only when the system is starting.
Second acceleration ramp time, adjustable from 0.1 to 999.9 s
Time to accelerate from 0 to the Rated motor frequency FrS page 55
. Make sure that this value is
compatible with the inertia being driven.
Visible only if PID feedback assignment PIF page 70
and PID predictive speed SFS page 71 are not set to
nO.
PIC
nO
YES
• PID correction reverse
nO
This parameter will reverse the internal error value of PID system.
• No
• Yes
Visible only if PID feedback assignment PIF page 70
is not set to nO.
PAU
• PID auto/manual assignment
nO
nO
L1H
L2H
L3H
L4H
At state 0 of input, PID is active.
At state 1 of input, manual run is active
• No
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI3 active high
• L4h: LI4 active high
Visible only if PID feedback assignment PIF page 70 is not set to nO.
PIM
• PID manual reference
nO
nO
A11
A1U1
This parameter allows to disable the PID and to run on a standard manual system.
• No
• Terminal
• AIU1
Visible only if PID feedback assignment PIF page 70
and PID auto/manual assignment PAU page 72 are
not set to nO.
tLS
• Low speed operating time
0.1 to 999.9 s nO
Following operation at Low speed LSP page 75 for a defined period, a motor stop is requested
automatically. The motor restarts if the frequency reference is greater than Low speed LSP and if a run
command is still present.
Important: nO value corresponds to an unlimited period.
Visible only if PID feedback assignment PIF page 70
is not set to nO.
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
