73
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
PId-
PID menu (continued)
rSL
• PID wake up level
0 to 100% 0%
If PID functions and Low speed operating timetLS are set at the same time, the PID regulator may try to
set a speed lower than LSP, resulting in unwanted operation consisting of start, running at LSP, stopping
and so on…
Parameter PID wake up level rSL is used to set a minimum PID error threshold to restart after a prolonged
stop at LSP.
Visible only if PID feedback assignment PIF page 70
and Low speed operating time tLS page 72 are not
set to nO.
UPP
• Wake-up threshold
0 to 100% 0%
If PID correction reverse PIC page 72 is set to nO, enables to set the PID feedback threshold beyond which
the PID regulator is reactivated (wake-up), following a stop caused by exceeding the tLS maximum time in
low speed.
If PIC is set to YES, enables to set the PID feedback threshold above which the PID regulator is reactivated
(wake-up), following a stop caused by exceeding the tLS maximum time in low speed.
Visible only if PID feedback assignment PIF page 70
and Low speed operating time tLS page 75 are not
set to nO.
Parameter that can be modified during operation or when stopped.
