77
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FLt-
Fault detection management menu
rSF
• Detected fault reset assignment
nO
nO
L1H
L2H
L3H
L4H
Manual fault reset.
• Function inactive
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI3 active high
• L4h: LI4 active high
Faults are reset when the assigned input or bit changes to 1, if the cause of the fault has disappeared.
The STOP/RESET button on the graphic display terminal performs the same function.
See also Diagnostics and Troubleshooting on page 87
.
Atr-
Automatic restart menu
Atr
• Automatic restart
nO
DANGER
UNINTENDED EQUIPMENT OPERATION
Check that an automatic restart will not endanger personnel or equipment in any way.
Failure to follow these instructions will result in death or serious injury.
nO
YES
This function allows defining the drive behaviour after a fault.
If validated, this function allows an automatic restart following a fault if the cause of the fault has
disappeared and the other operating conditions permit the restart.
• Function inactiv
• Automatic restart, after locking on a fault, if the fault has disappeared and the other operating
conditions permit the restart. The restart is performed by a series of automatic attempts separated by
increasingly longer waiting periods: 1 s, 5 s, 10 s, then 1 minute for the following attempts.
The drive fault relay remains activated if this function is active. The speed reference and the operating
direction must be maintained.
Use 2-wire control (Type of control tCC page 47
= 2C and 2 wire type control tCt page 50 = LEL).
If the restart has not taken place once the Max. automatic restart time tAr has elapsed, the procedure is
aborted and the drive remains locked until it is turned off and then on again.
The faults, which permit this function, are listed on page 89
:
tAr
• Max. automatic restart time
5 min
5
10
30
1H
2H
3H
Ct
• 5 min
• 10 min
• 30 min
• 1 hour
• 2 hours
• 3 hours
• Infinite
Visible only if Automatic restart Atr is not set to nO. It can be used to limit the number of consecutive
restarts on a recurrent fault.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
