76
Configuration Mode - Complete menu (FULL)
High speed configuration
The logic inputs enable selection of the desired high speed.
Desired
High speed
Setting
Parameter State
HSP SH2 nO
SH4 nO
HSP2 SH2 assigned
SH4 nO
HSP3 SH2 nO
SH4 assigned
HSP4 SH2 assigned
SH4 assigned
Code Name/Description Adjustment range Factory setting
FUn-
Function menu (continued)
SPL-
Speed limit menu
HSP
• High speed
LSP to tFr 50 or 60 Hz
according to BFr,
max TFr
Motor frequency at maximum reference, can be set between Low speed LSP and Maximum frequency tFr
page 55
.
If tFr is decreased below the value defined for HSP, then HSP automatically decreases to the new value
of tFr.
This parameter is already included in "my menu" section, page 44
.
SH2
• 2 HSP assignment
nO
nO
L1H
L2H
L3H
L4H
• No
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI3 active high
• L4h: LI4 active high
SH4
• 4 HSP assignment
nO
nO
L1H
L2H
L3H
L4H
• No
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI3 active high
• L4h: LI4 active high
HSP2
• High speed 2
LSP to tFr as HSP
Visible only if 2 HSP assignment SH2 is not set to nO.
HSP3
• High speed 3
LSP to tFr as HSP
Visible only if 4 HSP assignment SH4 is not set to nO.
HSP4
• High speed 4
LSP to tFr as HSP
Visible only if 2 HSP assignment SH2 and 4 HSP assignment SH4 are not set to nO.
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
