81
Configuration Mode - Complete menu (FULL)
Code Name/Description Adjustment range Factory setting
FLt-
Fault detection management menu (continued)
USb-
Undervoltage menu
USb
• Undervoltage fault management
0
O
1
Behavior of the drive in the event of an undervoltage
• Detected fault and R1 relay open.
• Detected fault and R1 relay closed.
StP
• Undervoltage prevention
nO
nO
rMP
Behavior in the event of the undervoltage fault prevention level being reached
• No action (freewheel)
• Stop following an adjustable ramp Undervoltage ramp deceleration time StM.
StM
• Undervoltage ramp deceleration time
0.0 to 10.0 s 1.0 s
Ramp time if Undervoltage prevention StP = rMP.
FLt-
Fault detection management menu (continued)
Strt
• IGBT test
nO
nO
YES
• No test
• The IGBTs are tested on power up and every time a run command is sent. These tests cause a slight
delay (a few ms). In the event of a fault, the drive will lock. The following faults can be detected:
- Drive output short-circuit (terminals U-V-W): SCF display
- IGBT faulty: xtF, where x indicates the number of the IGBT concerned
IGBT short-circuited: x2F, where x indicates the number of the IGBT concerned
LFL1
• 4-20 mA loss behaviour
nO
nO
YES
• Fault ignored. This configuration is the only one possible if AI1 current scaling parameter of 0% CrL1
page 51
is not greater than 3 mA or if AI1 type AI1t = 10U.
• Freewheel stop.
InH
• Detected fault inhibition assignment
nO
nO
L1H
L2H
L3H
L4H
To assign fault inhibit, press and hold down the “ENT” key for 2 s.
• Function inactive
• L1h: LI1 active high
• L2h: LI2 active high
• L3h: LI3 active high
• L4h: LI4 active high
CAUTION
RISK OF EQUIPMENT DAMAGE
Inhibiting faults results in the drive not being protected. This invalidates the warranty.
Check that the possible consequences do not present any risk.
Failure to follow these instructions can result in equipment damage.
To change the assignment of this parameter press the “ENT” key for 2 s.
Parameter that can be modified during operation or when stopped.
I-O-
drC-
CtL-
FUN-
FLt-
COM-
2 s
2 s
