5.2.6 Charging Terminated
Charging energy
Charging duration
Charging power
•
When problems occur with this charger or the charging process a status code will
display on screen as below illustrated. Please follow the troubleshooting table to
solve the problem.
5.2.7 Status Messages
Status Code
Charging summary page
•
After charging is terminated the charger system will show the Charging
Summary page as below illustrated and the charging connector will auto -
matically unlock.
•
Unplug the charging connector from charging inlet of the EV and return
the charging connector to charging cable holder.
•
The screen will go back to the Home Page or the other charging connec -
tor
’
s Charging Page if unplugged from the charging connector.
•
During simultaneous charging the screen will go to the other charging
connector
’
s Charging Page if either charging connector is unplugged.
