Blodgett BCX14E - Logic Board LED Designations Flow

BCX14E
BCX14E LOGIC BOARD LED INDICATOR DESIGNATIONS
B l o d g e t t O v e n
Page 33
LOW FLOAT LEVEL LED'S
BOILER PREHEAT TO 185F
LED On = INPUT LED On = INPUT
AMBER
-
INPUT LED'S
AMBER
-
INPUT LED'S
LED DESCRIPTION LED DESCRIPTION
1
Flush Disable (above 140F) J2-2
1
Flush Disable (above 140F) J2-2
2
Combi Mode J3-1
2
Combi Mode J3-1
3
Steam Mode J3-2
3
Steam Mode J3-2
4
Steam On Demand J3-7
4
Steam On Demand J3-7
5
Spare input J3-8
5
Spare input J3-8
6
Heat Demand J4-1
6
Heat Demand J4-1
7
Boiler High limit J4-5
7
Boiler High limit J4-5
8
Boiler Lo_Lvl_Float
8
Boiler Lo_Lvl_Float
9
Convection Heat J3-6
9
Convection Heat J3-6
LED On = OUTPUT LED On = OUTPUT
GREEN OUTPUT LED'S
GREEN OUTPUT LED'S
10 Boiler Heat On 10 Boiler Heat On
11
Delime lamp Flashing / Delime Oven
11
Delime lamp Flashing / Delime Oven
12
Steam On Demand Lamp J4-3
12
Steam On Demand Lamp J4-3
13 Convection Heat On J4-3 13 Convection Heat On J4-3
14 Drain Valve On J3-10 14 Drain Valve On J3-10
15 Boiler Fill Enable, J2-3 15 Boiler Fill Enable, J2-3
16 Delime Solenoid, J2-5 16 Delime Solenoid, J2-5
17 Spare Output, J3-5 17 Spare Output, J3-5
HOT AIR MODE LED'S
STEAM MODE LED INDICATORS
LED On = INPUT LED On = INPUT
AMBER
-
INPUT LED'S
AMBER
-
INPUT LED'S
LED DESCRIPTION LED DESCRIPTION
1
Flush Disable (above 140F) J2-2
1
Flush Disable (above 140F) J2-2
2
Combi Mode J3-1
2
Combi Mode J3-1
3
Steam Mode J3-2
3
Steam Mode J3-2
4
Steam On Demand J3-7
4
Steam On Demand J3-7
5
Spare input J3-8
5
Spare input J3-8
6
Heat Demand J4-1
6
Heat Demand J4-1
7
Boiler High limit J4-5
7
Boiler High limit J4-5
8
Boiler Lo_Lvl_Float
8
Boiler Lo_Lvl_Float
9
Convection Heat J3-6
9
Convection Heat J3-6
LED On = OUTPUT LED On = OUTPUT
GREEN OUTPUT LED'S
GREEN OUTPUT LED'S
10 Boiler Heat On 10 Boiler Heat On
11
Delime lamp Flashing / Delime Oven
11
Delime lamp Flashing / Delime Oven
12
Steam On Demand Lamp J4-3
12
Steam On Demand Lamp J4-3
13 Convection Heat On J4-3 13 Convection Heat On J4-3
14 Drain Valve On J3-10 14 Drain Valve On J3-10
15 Boiler Fill Enable, J2-3 15 Boiler Fill Enable, J2-3
16 Delime Solenoid, J2-5 16 Delime Solenoid, J2-5
17 Spare Output, J3-5 17 Spare Output, J3-5
