Symbol Description Diagram
SYM
DESCRIPTION
BCX-2 24DCV BX Series BC2 Logic Board
CON4
24DCV Power Supply
CR1
Relay, Oven, On/Off
DS5
Power On Light
DS6
Heat Demand Light
DS7
Low
Water light
DS8
Delime Light
DS9
Steam On Demand Light
IFB
Interface Relay Board
K1
Hot Air Contactor
K1_Aux
Hot Air Auxiliary Contact
K2
Steam Contactor
K2_Aux
Steam Auxiliary Contact
MTR1
Convection Fan Motor 220V
MTR2
Cooling Fan
MTR3
Boiler
Drain Valve
Prb1
-
1
Cavity Temperature Probe
Prb2
-
1
Meat Temperature Probe
R1
Temperature Control Potentiometer
R7
Steam On Demand Potentiometer
RT1
Thermostat
5 Ohm @ 25C
SW1
Mode Selector Switch
SW2
Light Switch
SW3
Vent Switch
SW4
Cavity/Boiler
High Limit
SW6
Heat Cut off Switch
SW7
Flush Disable Switch
SW8
Door Switch Proximity
SW9
Convection Motor Rotary Switch
SW10
Steam On Demand Switch
SW11 Boiler Preheat Switch open @ 185
SW15 Cooling Fan Switch Close @ 110
SW16 Quench Thermostat Close @ 150
T1
Hot Air Transformer 208/24ACV
T2
Steam Transformer 208/24ACV
TR1
Terminal Block Incoming Power Supply
TB2
Terminal Block Oven Interior Lights
TC1
Temperature Control
TMR1
Programmable Motor Reverse Timer
U6
Programmable Motor speed
Inverter
U7
Hot Air Ignition Spark Module 1
U8
Hot Air Ignition Spark Module 2
U9 Steam Ignition Spark Module
