Blodgett BCX14E - IFB (LED) Designations Flow

BCX14E
BCX14E IFB RELAY BOARD LED DESIGNATIONS
B l o d g e t t O v e n
Page 35
BCX14 Interface Board
LED Designations
Part # 39672
Lights On
indicate (Energized Relays) active circuits as labeled.
CR7 (D71)
Boiler Heat
CR1 (
D11)
Heat Enable
CR8 (D81)
Fill Enable
CR10 (D101)
Boiler Drain
Quench Sol.
(D9)
CR2 (D21)
Door Closed
CR3 (D31)
Oven On
CR4 (D41)
Cooling Fan
CR5 (D51)
Vent
Delime Sol.
(D8)
CR6 (D61)
Lights
J1 J2
J3
J4
J8
J7 J6 J5
#1
#1
#1
