Introduction
3
Oven Components
Heating Elements --- located on the side of the
oven, the elements provide heat to the baking
chamber on electric ovens.
Control Panel --- contains wiring and components
to control the oven operation.
Oven Racks --- five racks are provided standard.
Additional racks are available.
Rack Supports --- h o l d o v e n r a c k s .
Blo wer Wheel Cover --- located on the side interi -
or wall of the oven. Protects the blower wheel.
Blo wer Wheel --- spins to circulate hot air in the
baking chamber.
Convection Motor --- provides power to turn the
blower wheel.
CTB CTBR
Figure 1
