Installation
10
Electrical Connection
Wiring diagrams are located in the control comĆ
partment area.
Ovens are supplied for operation in several voltĆ
age choices, single or three phase grounded cirĆ
cuits.
The electric motor, indicator lights and related
switches are interconnected through the one powĆ
er source supplied to the oven.
1. The supply conduit enters through the rear of
the oven and electrical block secured to the
perforated panel at the back of the control
compartment.
THE BLODGETT OVEN COMPANY CANNOT ASĆ
SUME RESPONSIBILITY FOR LOSS OR DAMAGE
SUFFERED AS A RESULT OF IMPROPER INSTALĆ
LATION.
