1.3.3 CO2 Waveform Display Mode
Fig 1-6 CO2 Display Mode
1. CO2
waveform display area: Waveform shown in the area
is current CO2 waveform 。
2. CO2 parameter area: The values shown in the area are
current HR value and its higher and lower alarm limits.
3. RR parameter area: The values shown in the area are
current RR value and its higher and lower alarm limits.
1
2
3
