• Mode 2
In the absence of a PV system, the load is powered by the backup battery. When the
battery charge is depleted, the system automatically switches to grid power to
continue supplying the load.
• Mode 3
If the grid is disconnected, the PV and backup batteries work together to provide
power to the load.
Figure 2-3
Figure 2-4
Grid
Solar panels
BLUETTI APP
B500
AC loads
EP760
Green Energy
Public Grid Energy
Hybrid Energy
EP760
Grid
Solar panels
B500
AC loads
BLUETTI APP
Green Energy
Public Grid Energy
Hybrid Energy
