4.3.2. Interface Description
Interface
⑦ Inverter signal
port(PCS LINK)
For communication between inverter and battery packs. Connect to the
LINK PORT 2 of EP760 inverter via the battery communication cable.
Connect to the BAT+ terminal of another B500 or EP760 inverter.
Connect to the BAT- terminal of another B500 or EP760 inverter.
For communication between battery packs. Connect to the battery
pack signal output port of the upper battery via the communication
cable when multiple B500s are stacked.
For communication between battery packs. Connect to the battery
pack signal input port of the lower battery via the communication
cable when multiple B500s are stacked.
②Battery pack
signal input port
（PACK LINK IN）
③Battery pack
signal output port
（PACK LINK OUT）
⑨BAT+ terminal
④BAT- terminal
Description
Table 4-4
4.4 LED Indicators
Light
OFF B500 is not started. Can operate the circuit breaker.
Can not operate the circuit breaker.
Can not operate the circuit breaker.
B500 is running.
B500 is shutting down.
B500 is not running.
ON
Flash at 0.5Hz
Flash at 1Hz
Description Note
If all indicators are flashing, the battery
module is temporarily unavailable and is
restoring, please wait patiently.
If it lasts for more than 1 hour, please
contact an authorized dealer or our
company.
If a single indicator flashes, the B500 is in
a fault condition. Please contact an
authorized dealer or our company.
Table 4-5
