JUST POWER ON70
Battery
Item
Model
Number of Battery in Parallel
Description
B500
2-4
Charging Strategy BMS Orders (CC/CV)
PV Input
Item
Maximum Input Power
MPPT Channel
Array in Series
Maximum Input Voltage
MPPT Voltage Range/Rated
Single MPPT Maximum Input Current
Single MPPT Maximum Short-circuit Current
MPPT Efficiency
PV Inversion Efficiency
Description
9kW (3kW for each channel)
3
1
550V
150V~500V/360V
12.5A
15A
99.9%
96.0% Max.
10.2. DC Interface
Reverse polarity protection
Insulation resistance detection
Protection
Maximum Output Power
7.6kW
If only one B500 is connected, the output is 5 kW.
