Speedmachine Owners Manual
Base bar
Base bar Flat
The standard base bar delivered on Speedmachine is the “flat base bar”.
Width : 400mm
Article numbers:
30006136 CKP BASE 24-R6, 0, FLAT-400, RED
30006138 CKP BASE 24-R6, 0, FLAT-400, CBN
Base bar Low
The optional “low base bar” provides a lower stack and a longer reach
Width: 400mm
Armrest:
• Stack: -32.8mm
• Reach : +35mm
Grips:
Stack: -42.5mm
• Reach: 0mm
Article numbers:
30006135 CKP BASE 24-R6, 0, LOW-400, CBN
30006137 CKP BASE 24-R6, 0, LOW-400, RED
Headset bearings
Article numbers:
30006294 Headset Bearings SM00/01
30006296 Headset Sleeve SM00/01 (includes Rotation stop)
Extension set
The base bar of the Speedmachine is design for Profile Design Aeria 3 Ultimate.
A3 riser kit (60mm)
Bridge (5mm)
A3 adpator
Aeria Ultimate bracket
Ergo+ armrest
10mm pads
45/25 SLC extensions
This design and its components provide a wide range of adjustment.
0
105
105 range
0
65
65 range
124 253
129 range
Article numbers:
30006299 Extensions Adapter and Riser Kit SM00/01
Depending on your frame size
and in combination with the
high or low base bar, you can
reach a wide range of armrest
positions.
Please refer to “Sizing and
parts selection for the Speed-
machine” page 14 for details.
