BMG LABTECH Omega Operating Manual
2014-05-16 0415B0001G 15/29
Top View, Reagent Box
Figure 6: FLUOstar Omega & POLARstar Omega top view of reagent box with
spectrometer based absorbance and 2 reagent injectors; no top optic is installed
Filter wheel cover
(for emission filter wheel and
excitation filter wheel)
Transport lock
Reagent injectors (optional)
Measurement
head position
Bottom optic
Absorbance optic
Injection needle holder
