BMG Labtech FLUOstar Omega - 4 Instrument Overview

Omega Operating Manual BMG LABTECH
14/29 0415B0001G 2014-05-16
Reagent box
Plate carrier
Plate In / Plate Out button
4 Instrument Overview
Front View
Figure 4: FLUOstar Omega
A constant green light means the instrument is turned on. A flashing green light means the instrument is
busy (e.g. performing a measurement, plate in/out, priming, etc.). A faster flashing green light (5 flashes per
second) means an error has occurred.
Back View
Figure 5: Back view of reader
Instrument turned on/busy light
USB
connection
Stacker
connection
Power cable
connection
On/Off
switch
Serial
number
