Install the rear wheel
WARNING
Use of a non-standard wheel.
Malfunctions in operation of ABS.
See the information on the
effect of wheel size on the
ABS system at the start of this
chapter.
ATTENTION
Tightening threaded fasten-
ers to incorrect tightening
torque.
Damage, or threaded fasteners
work loose.
Always have the security of
the fasteners checked by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.
Position brake-caliper carrier 1
on guide 2.
Roll the rear wheel into the
swinging arm, making sure that
the brake disc passes between
the brake pads.
Roll the rear wheel as far
forward as possible and loop
chain 8 over the sprocket.
Seat left adjusting plate 7 in
the swinging arm and install
quick-release axle 6 in the
9
