Insert bulb 1 into socket 2.
Insert plug 1 into the headlight
and turn it clockwise to lock.
Replacing bulb for brake
light and rear light
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Switch off the ignition.
Remove screws 1.
Ease the glass to the rear to
remove.
Remove bulb 2 for the brake
light and rear light.
Replace the defective bulb.
Bulb for tail light/brake
light
P21/5W / 12 V / 5 W / 21 W
Use a clean, dry cloth to hold
the bulb in order to keep the
glass free of foreign matter.
9
114
z
Maintenance
