Pin Assignments (6-Cylinder)
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
207 Not used
208 A Torque converter clutch solenoid valve
control (–)
Transmission valve unit
209 A Solenoid valve 2 control (–) Transmission valve unit
210 M Ground Ground point
211 Not used
212 E Gear range signal L1 Automatic transmission range switch
213 E Gear range signal L3 Automatic transmission range switch
214 Not used
215 Not used
216 Not used
217 Not used
218 E Output speed (+) Transmission valve unit
219 Not used
220 Not used
221 A A-program indication Program switch
222 Not used
223 Not used
224 E Brake switch test signal Brake light switch
225 Not used
226 Not used
227 Not used
228 A Shift-lock solenoid control Shift-lock
229 A Voltage solenoid valves Transmission valve unit
230 E Voltage supply terminal 87 Engine control module relay
