6575.2 ANTI–THEFT SYSTEM (ALPINE)
04/99
6575.2Ć
1998
00
P90
FRONT POWER
DISTRIBUTION BOX
N12w
ANTI–THEFT
CONTROL MODULE
(ALPINE)
FUSE DETAILS
0670.3
F43
5A
2
3 9
X450
X13025
X10010
GROUND
DISTRIBUTION
0670.4
.5 GN/WS
8
2 X65
.5 BL/GN/GE
N17
CRASH CONTROL
MODULE
1 X10244
.5 VI/GN/GE
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
X1225
26
FUSE DETAILS
0670.3
F31
5A
1 X13025
2 X10018
17 X132534
10
14 X1659
A836
ELECTRONIC
IMMOBILIZER
CONTROL MODULE
(EWS II)
21
S20w
RADIO ANTI–
THEFT SWITCH
1) RADIO
REMOVED
2) RADIO
INSTALLED
2 X539
1 X539
X18170
GROUND
DISTRIBUTION
0670.4
21
S21w
ENGINE HOOD
SWITCH
1) HOOD OPEN
2) HOOD CLOSED
2 X371
1 X371
X166
GROUND
DISTRIBUTION
0670.4
.5 VI/GN/GE
.5 VI/GN/GE
.5 BL/RT/GE.5 BL/RT/GE
.5 BL/RT/GE
