ANTI–THEFT SYSTEM (ALPINE)
04/99
6575.2Ć
1998
01
P90
FRONT POWER
DISTRIBUTION BOX
N12w
ANTI–THEFT
CONTROL MODULE
(ALPINE)
FUSE DETAILS
0670.3
F43
5A
2
3 11
1 X711
X465
.75 BR/WS
X10010
GROUND
DISTRIBUTION
0670.4
.5 BR/WS
.75 BR/WS
12
LICENSE PLATE/
LUGGAGE
COMPARTMENT
LIGHTS
6320.0
26
H1w
ANTI–THEFT HORN
(ALPINE)
2 X372
1 X372
X9633
GROUND
DISTRIBUTION
0670.4
1 SW/BL
12
X443
S14
DRIVER’S DOOR
JAMB SWITCH
1) DOOR OPEN
2) DOOR CLOSED
2 X352
.75 BR/GR/GE
X13006
GROUND
DISTRIBUTION
0670.4
1 X352
12
S13
PASSENGER’S
DOOR JAMB
SWITCH
1) DOOR OPEN
2) DOOR CLOSED
2 X351
.75 BR/BL/GE
1 X351
X13004
X445
GROUND
DISTRIBUTION
0670.4
7 X13025
A2w
INSTRUMENT
CLUSTER
23 X17
.5 BR/GR/GE
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
2 X132543
4 5
.75 BR/GR/GE .75 BR/BL/GE.5 BR/GR/GE
FUSE DETAILS
0670.3
F31
5A
1 X13025
2 X10018
.5 BR/BL/GE
S826
LUGGAGE
COMPARTMENT
LIGHT SWITCH
1) REAR LID
CLOSED
2) REAR LID
OPEN
2 X711
X13006
GROUND
DISTRIBUTION
0670.4
