ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)
BMWBMW
04/99
2460.2Ć
1998
08
P90
FRONT POWER
DISTRIBUTION BOX
L4 L3 L2 L1
A8500
TRANSMISSION
CONTROL MODULE
(EGS)
9 37 8 36 X8500
86 74
.5 BR/WS .5 BL/WS .5 BR/SW .5 BL/SW
X5113
S3
AUTOMATIC
TRANSMISSION
RANGE SWITCH
0) OFF (LOW)
1) ON (HIGH)
2) CLOSED IN
REVERSE
2 X5115
L4 L3 L2 L1
R
E16
LEFT REAR LIGHT
ASSEMBLY
5 X319
21
20 19 X69
18
A8
CRUISE CONTROL
MODULE
(TEMPOMAT)
25 X22
9 X1659
A836
ELECTRONIC
IMMOBILIZER
CONTROL MODULE
(EWS II)
.5 BR/SW
.5 BR/WS .5 BL/WS .5 BR/SW .5 BL/SW
.5 BR/SW
FUSE DETAILS
0670.3
L1 L2 L3 L4
P
R
N
D
3
2
1
1101
1000
1110
0001
0011
1011
0010
H27
LEFT BACK UP
LIGHT
16
X1001712
X1169
1 BL/GE
FUSE DETAILS
0670.3
1 BL/GE
L2
L2
.5 BR/SW
BM
BMW
BMWBMW
Z3
F28
5A
F26
10A
1001 01 01
20
31
31 31 31
X191
2 X18994
.35 BR/SW
NOT USED
