6211.0Ća
1998
Pin Assignments
04/99
BM
BMW
BMWBMW
Z3
E = Input, A = Output, M = Ground
X16
Pin Type Description/Function Connection
1 E High beam indicator control Combination switch
2 E Terminal 58g, instrument illumination power Light switch (dimmer)
3 E Right turn signal indicator control Hazard flasher relay
4 E Left turn signal indicator control Hazard flasher relay
5 E Warning lamp for EGS fault (information
signal transmission oil temperature)
Transmission control module (EGS)
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
11 A Diagnosis RxD signal Data link connector (M Roadster)
12 E/A Diagnosis TxD signal Data link connector
13 Not used
14 E Airbag warning lamp (SRS) control Supplemental restraint system control
module
15 Not used
16 E “Check engine” indicator control Engine control module (DME)
17 E Park brake warning lamp control Park brake switch
18 E Brake fluid warning lamp control Brake fluid level switch
19 E Brake pad wear warning lamp control Brake pad sensors
20 E Crankshaft RPM speed signal TD Engine control module (DME)
21 Not used
22 E Voltage supply, terminal 30 Front power distribution box, fuse 31
23 E Voltage supply, terminal 15 for indicator and
warning lamps
Front power distribution box, fuse 27
24 M Ground supply, terminal 31 for instrument
cluster electronics
Ground point
25 Not used
26 Not used
