BLT4102 Product Manual
7
4.1 EtherCAT Controller
Hypcut
IPC
Master
Station
Slave Station
HyPanel
BCS210E
Power Supply
220V AC
 Notice:
 The above wiring operations should only be performed by trained and
professional personnel.
 When the cutting head is connected to the BCS210E, the BCS210E must
be powered off.
BLT4102 Cutting Head Installation
Wiring Diagram
