BLT4102 Product Manual
13
5.2.9 Installing the ceramic body and nozzle
Install the ceramic body and secure with the locking ring, then install the nozzle.
Tighten the nozzle on the
Tighten the nozzle on the ceramic body by hand,
Use a wrench to tighten the ceramic locking ring.
Ceramic Part
Locking Ring
Nozzle
