Appendix A - Care/Maintenance
A.1 Schematic Diagram of Product Structure
F300mm
Q+/AD
D
Laser Fiber
Q+
ADD
Collimating
Cartridge Unit
Focal length
Collimation
F100mm
Focusing Cartridge
Focusing Length
F300mm
Upper Protective
Window Cartridge
Upper Protective
Window D25.4T4-10
2nd-Upper Protective
Window Cartridge
2nd-Upper Protective Window
D25.4T4-10
2nd-Lower
Protective Window
Cartridge
2nd-Lower Protective
Window
D34.0T5-10
1st-Lower Protective
Window Cartridge
1st-Lower Protective Window
D34.0T5-10
Lower Protective Window
Spring Seal
SRLC-P385
Anti-Collision
Set
DP.M.Q0210AA
Lower Protective
Window Cover
DP.M.Q0236AA
Plane Capacitance Sensor
Module
Ceramic Part
M11*0.75
Nozzle
M11*0.75 Thread
Bevel Capacitance
Sensor Module
Ceramic Part
M11*0.75
Nozzle
M11*0.75 Thread
