BLT4102 Product Manual
2
1.2 Technical Parameters
Cutting Head BLT4102
Laser Wavelength: 1030-1090nm
Laser Power: ≤40kW
Fiber Interface: Q+/ADD
Spot Magnification: M=3.0
Max Focus Adjustment Range: ±50mm
NA: Max.0.13 at Fc100
Centering Adjustment Range: ±1.5mm
Focus Acceleration: 7.5m/s²
Cutting Gas Interface: ø10, maximum 25bar (2.5Mpa)
Nozzle Cooling Gas Connection: ø6, maximum 5bar (0.5Mpa)
Water Cooling Interface: ø8, maximum 5bar (0.5Mpa), minimum flow 2.0l/min
Operating Temperature: 5 ～ 55 ℃
Storage Temperature: -25～+55 ℃
Dimension: 524x122
Weight： 7kg (M=3.0)
Notice:
To avoid damage to the cutting head during storage and transportation, pay attention to the
following:
The cutting head should be stored within the allowable temperature and humidity range.
Avoid storage in and near magnetic fields such as permanent magnets or strong alternating
