BLT641 Product Manual
17
5.2.9 Installing the ceramic body and nozzle
Install the ceramic body and secure with the locking ring, then install the nozzle.
A
B
C
D
ceramic body
locking ring
nozzle
Tighten the nozzle on the ceramic body
by hand,
Use a wrench to tighten the ceramic
locking ring.
