BLT641 Product Manual
5
1.2 Technical parameters
Cutting head
BLT641
Laser wavelength:
1030-1090nm
Laser power:
15KW
Fiber interface:
QBH,QD,Q+,ADD
Spot magnification:
M=2.0
Focus adjustment range:
±50mm (optical ratio 1:2 100:200)
NA:
Max.0.13 at Fc100
Centering adjustment range:
±1.5mm
Focus acceleration:
7.5m/s²
Cutting gas interface:
ø10, maximum 25bar (2.5Mpa)
Nozzle cooling gas connection:
ø6, maximum 5bar (0.5Mpa)
Water cooling interface:
ø8, maximum 5bar (0.5Mpa), minimum flow 2.0l/min
Operating temperature:
5～55℃
storage temperature:
-25～+55 ℃
size:
472.3x181
weight:
About 11 kg
Notice:
To avoid damage to the cutting head during storage and transportation, pay attention to the
following:
 The cutting head should be stored within the allowable temperature and humidity range.

Avoid storage in and near magnetic fields such as permanent magnets or strong alternating
fields.
 Avoid collision of the cutting head.
