BLT641 Product Manual
19
Manual alignment operation:
1. Make sure the laser beam is turned off.
2. Place scotch tape under the nozzle.
3.
Click to trigger a low-power laser pulse and assess the position of the laser beam relative to the
nozzle through the penetration of the tape.
4. Adjust the X/Y centering screws to center the laser beam on the nozzle.
